Descripción
Electrical Specification |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Input Voltage Range |
100Vac-240Vac |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Efficiency |
≥77.76% |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Output Voltage |
DC12V |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Rated Output Current |
1A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Output Power |
12W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
No Load Power Consumption |
≤0.3W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protection/Environmental |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Surge Protected |
Line to ground: ±4KV Line to line: ±2KV |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ESD |
Contact discharge: ±4KV Air discharge: ±8KV |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protective Function |
Over voltage protection, over current protection, short circuit protection, input protection |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working Temperature |
0°C ~ +40°C(32 °F ~ +104 °F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Working Humidity |
10%~90%(RH) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Temperature |
- 40°C ~ + 80°C( - 40 °F ~ + 176 °F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Humidity |
5%~95%(RH) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Physical Properties |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Installation |
Wall-mount |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Net Weight |
0.074kg(0.16lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Gross Weight |
0.089kg(0.19lb) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimension |
60.6 mm × 29.0 mm × 40.0 mm (2.39" ×1.14" ×1.57") (L × W × H) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Package Dimension |
85.0 mm × 83.0 mm × 32.0 mm (3.35" ×3.27" ×1.26") (L × W × H) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Color |
Black |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Input Plug |
2-pin North American plug |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Output Cable Length |
1500 mm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Output Plug |
Φ5.5 mm × Φ2.1 mm × 10 mm (Φ0.22" × Φ0.08" × 0.39") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Safety Standards |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification |
FCC |
